ultra-compact

ocean microspectrometers are ideal for integration into oem devices and inline controls with limited space and deliver powerful performance.

specifications:
wavelength range	180 – 650 nm	350 – 810 nm	646 – 1085 nm
integration time	3.8 ms – 6 s	3.8 ms – 6 s	3.8 ms – 6 s
optical resolution (fwhm)	2.2 nm	2.2 nm	2.2 nm
snr (single scan @ 10 ms)	190:1	190:1	190:1
snr (max. per second w/high speed averaging mode)	2,250:1	2,250:1	2,250:1
connectors	sma 905 (input fiber)	sma 905 (input fiber)	sma 905 (input fiber)
physical dimensions	42.1 x 40.3 x 26.6 mm	42.1 x 40.3 x 26.6 mm	42.1 x 40.3 x 26.6 mm
temperature (operation)	0 °c – 55 °c	0 °c – 55 °c	0 °c – 55 °c
temperature (storage)	-30 °c – 70 °c	-30 °c – 70 °c	-30 °c – 70 °c
best for	integration into other devices	color measurement integration into other devices led characterization	integration into other devices materials reflectance
